HDB-III Transformer Ratio Tester



Introduction

HDB-III Transformer Ratio Tester is specially designed for three-phase transformer in power system, especially for transformer of type Z winding and other transformers whose zero-load current is relatively high. The tester has wide testing range, fast testing speed, favorable repeatability, flexible data processing, convenient connection, complete protection, easy learning and convenient operation.

Features

1.Applicable to transformers connected in Z type.

2.Two output voltages are optional and applicable to transformer whose zero-load current is relatively high.

3.Have wide testing range and the highest transformation ratio may reach 10000.

4.Automatically calculate tap position.

5.Fast speed, which is only 18 seconds for three-phase.

6.Favorable repeatability.

7.Automatically save 99 data at most.

8.Flexible data processing, including retrieval, print, transfer to U-disk, delete and upload to PC computer for testing.

9.Have transformer short-circuit protection and interturn short-circuit protection functions. In case of short circuit, relevant information will be displayed on the LCD screen in characters.

10.The upper computer could control the whole testing process, save data.

Parameters

Ratio testing range	1～10000
Group testing range	1～12
Accuracy	1～1000, 0.2
	1000～10000 ,0.5
Power	AC230V ±10%, 50HZ
Temperature	-20℃～40℃
Relative humidity	＜85%
Dimension	325mm×278mm×188  mm
Weight	6.9Kg



FAQ:

1. When can I get the price?

We usually quote within 6 hours work time after we get your inquiry. If you are very urgent to get price, please call us or tell us in your email so that we will regard your inquiry priority.

2. What about the delivery time for production?

Honestly, it depends on the order quantity and the product. Usually our leading time is within 7 working days after order confirmation.

3. What is your payment terms?

We accept EXW, FOB, CFR, CIF, DDU, ect. You can choose the one which is the most convenient and cost effective for you.

4. How much will the Shipping cost and time be?

This will depend on size of your goods and method of shipping (by sea/ by air/by Express) and your designated seaport or airport. We will be grateful if you can spare us some minutes to evaluate the cost based on the information of product.

5. Could you please tell me the Warranty Period of your product?

Our warranty period is one year free and lifelong maintenance. If the product is damaged (if not man-made damage), in the first year,we will send free parts for replacement. Over warranty, maintenance is paid service.

6. Do you have Technical Backup to all customers from different countries?

To be sure,our technical support is always available and quick response.
We are manufacturer with much on-site testing experience, thus we know how to deal with your problems. Moreover, our engineers can go to your country to support if needed.
