Description



HD-TC Cable Fault Detector



 More information:

Project, News, Video，please kindly click the letters to view:

Product: HV-TC Cable Fault Detector

Tutorial Video Of HV-TC1 & TC2 Cable Tracker and fault locator

Tutorial Video Of HV-TC Cable Fault Detector and HVG High Voltage Generator

News: HV-TC Cable Fault Detector SOLD to our Australian Customer for their state-cross buried lines

PROJECT: HV-TC Cable Fault Detector

Tutorial Video Of HV-TC Cable Fault Detector （Host）



Introduction

The normal operation of cable-communication and electric transport completely rely on the good condition of the cable-circuit. Once the circuit breaks down and without punctually examination and repairing, it will no doubt trigger the mass economic loss and bad social influence. So the electric fault measuring testing instrument is a very important tool. The intellectual testing instrument uses multiple testing methods and adopts the most advanced electronic devices and with computer and special electronic technology, combining our company’s successful experience of long-time exploitation on cable-fault measuring testing instruments, and it is absolutely of high tech, intelligence and abundant functions.
Our cable-fault detector is a testing device of good integrity. It can test on the High Resistance Flashover Fault, Grounding High and Low Resistance Fault, Short & Off Circuit on the Cable Fault and Poor contact and etc. If being equipped with sounding method and locating instrument, it can exactly detect the fault point. Furthermore, it especially applies to test for various power cable and communication cable.

Product set and accessories:



Features

1.Multiple functions
Safe, quick and accurate to test. The instrument applies the methods of Low Voltage Pulse and High Resistance Flashover. It can test all kinds of faults, especially on the Flashover and High Resistance fault testing and without burning through. If it is equipped with sounding method and locating instrument, it can exactly point out the location of the fault.
2 High Precision
Our instrument uses the tech of high speed data sampling, the speed of A/D is 100MHz, and makes resolution ratio of 1m and testing dead zone of 1m.
3 High intelligent
The testing results automatically show by wave form and data on the large LED . It is easy for viewing. It does not need especial training for operators.
4 Function of Wave Form and Parameter Saving & Reading
It uses non-volatile devices and after turning off, it still saves the wave form and data.
5 Function of Double-trace Showing
It can compare the wave forms of fault-manner cables and those of the regular ones. It is benefit for the further testing of the fault.
6 Function of Magnifying on the Scale of Wave Form
Through magnifying the scale of the wave form, it can make further exact testing.
7 It can wantonly change the position of the cursor, showing the direct or indirect distance of fault point and testing point.
8 It has the function of changing the speed of communication depending on the tested cable.
9 The instrument is portable and with a chargeable battery to provide power. It is convenient to take and use.

Parameters



FAQ:

1. When can I get the price?

We usually quote within 6 hours work time after we get your inquiry. If you are very urgent to get price, please call us or tell us in your email so that we will regard your inquiry priority.

2. What about the delivery time for production?

Honestly, it depends on the order quantity and the product. Usually our leading time is within 7 working days after order confirmation.

3. What is your payment terms?

We accept EXW, FOB, CFR, CIF, DDU, ect. You can choose the one which is the most convenient and cost effective for you.

4. How much will the Shipping cost and time be?

This will depend on size of your goods and method of shipping (by sea/ by air/by Express) and your designated seaport or airport. We will be grateful if you can spare us some minutes to evaluate the cost based on the information of product.

5. Could you please tell me the Warranty Period of your product?

Our warranty period is one year free and lifelong maintenance. If the product is damaged (if not man-made damage), in the first year,we will send free parts for replacement. Over warranty, maintenance is paid service.

6. Do you have Technical Backup to all customers from different countries?

To be sure,our technical support is always available and quick response.
We are manufacturer with much on-site testing experience, thus we know how to deal with your problems. Moreover, our engineers can go to your country to support if needed.
